Home > Products > Others > Filters > Power Filter
| Rated Voltage | 250VAC |
| Operating Frequency | 50/60Hz |
| Rated Current | 3A - 15A |
| Test Voltage (1min) | 1500VDC (line/line); 1500VAC (line/ground) |
| Climatic Category | 25/085/21 |
| Model |
Rated Current （A） |
Ground Capacitance（nF） |
Leakage Current ≤（mA） |
Discharge Resistance（MΩ） |
| DL - 3DZ2 | 3 | 3.3 | 0.5 | - |
| DL - 6DZ2 | 6 | 3.3 | 0.5 | - |
| DL - 10DZ2 | 10 | 4.7 | 0.8 | - |
| DL - 15DZ2 | 15 | 2.2 | 0.5 | 1 |
