| Filter model | Rated current@40°C（A） | Leakage current@250VAC/50Hz（mA） | Input/Output Connections | Weight（g） |
| DL20030 - 1-06 | 1 | 0.31 | 6.3×0.8 | 65 |
| DL20030 - 3-06 | 3 | 0.47 | 6.3×0.8 | 100 |
| DL20030 - 4-06 | 4 | 0.47 | 6.3×0.8 | 105 |
| DL20030 - 6-06 | 6 | 0.66 | 6.3×0.8 | 110 |
| DL20030 - 8-06 | 8 | 0.66 | 6.3×0.8 | 200 |
| DL20030 - 10-06 | 10 | 0.66 | 6.3×0.8 | 210 |
| DL20030 - 12-06 | 12 | 0.79 | 6.3×0.8 | 190 |
| DL20030 - 16-06 | 16 | 0.79 | 6.3×0.8 | 250 |
| DL20030 - 20-.. | 20 | 0.79 | 6.3×0.8、M4 | 300 |
| DL20030 - 30-08 | 30 | 0.79 | M4 | 330 |
| DL20030S - 1-06 | 1 | 0.07 | 6.3×0.8 | 65 |
| DL20030S - 3-06 | 3 | 0.07 | 6.3×0.8 | 100 |
| DL20030S - 4-06 | 4 | 0.07 | 6.3×0.8 | 105 |
| DL20030S - 6-06 | 6 | 0.07 | 6.3×0.8 | 110 |
| DL20030S - 8-06 | 8 | 0.07 | 6.3×0.8 | 200 |
| DL20030S - 10-06 | 10 | 0.07 | 6.3×0.8 | 210 |
| DL20030S - 12-06 | 12 | 0.07 | 6.3×0.8 | 190 |
| DL20030S - 16-06 | 16 | 0.07 | 6.3×0.8 | 250 |
| DL20030S - 20-.. | 20 | 0.07 | 6.3×0.8、M4 | 300 |
| DL20030S - 30-08 | 30 | 0.07 | M4 | 330 |
| DL20030N - 1-06 | 1 | 0 | 6.3×0.8 | 65 |
| DL20030N - 3-06 | 3 | 0 | 6.3×0.8 | 100 |
| DL20030N - 4-06 | 4 | 0 | 6.3×0.8 | 105 |
| DL20030N - 6-06 | 6 | 0 | 6.3×0.8 | 110 |
| DL20030N - 8-06 | 8 | 0 | 6.3×0.8 | 200 |
| DL20030N - 10-06 | 10 | 0 | 6.3×0.8 | 210 |
| DL20030N - 12-06 | 12 | 0 | 6.3×0.8 | 190 |
| DL20030N - 16-06 | 16 | 0 | 6.3×0.8 | 250 |
| DL20030N - 20-.. | 20 | 0 | 6.3×0.8、M4 | 300 |
| DL20030N - 30-08 | 30 | 0 | M4 | 330 |
